ESAB Shield-Bright 2209 1.2 mm 4x5 kg
ESAB

ESAB Shield-Bright 2209 1.2 mm 4×5 kg

£317.62 ex VAT (£381.14 inc VAT)

Designed for the welding of 2205 stainless steel.

Available to order – ask us for a lead time

Sold in multiples of 4

  • Next-day delivery to UK mainland when ordered by 2pm: £8.35 ex VAT, free on orders of £100 ex VAT and over
  • Free collection from our Scotstoun warehouse
  • Secure card payments
  • Expert advice: 0141 959 5666
  • Trade accounts available – apply online
SKU: 35HC12560V Categories: , Brand:

Description

Shield-Bright 2209 was developed for the welding of “2205” duplex stainless steels (UNS S31803, S32205, and J92205).
It can also be used for the welding of leaner grades of duplex stainless steels.
It has been approved with a 25°C critical pitting temperature and impact toughness at -40°C (-40°F).

Technical specification



Typical Charpy V-Notch Properties

Impact Value Testing Temperature
As Welded 80%Ar/20%Co2 Shielding Gas (M21)
52 J (38 ft-lb) -46 degC (-51 degF)
As Welded Co2 Shielding Gas (C1)
50 J (37 ft-lb) -46 degC (-51 degF)

Typical Tensile Properties

Condition As Welded As Welded
Shielding Gas 80%Ar/20%CO2 Shielding Gas (M21) CO2 Shielding Gas (C1)
Tensile Strength 810 MPa (117 ksi) 800 MPa (116 ksi)
Yield Strength 670 MPa (97 ksi) 650 MPa (94 ksi)
Elongation 28 % 28 %

Deposition Data

Current Deposition Rate Diameter Voltage Wire Feed Speed
130-220 A 1.9-4.6 kg/h (4-10 lb/h) 1.2 mm (0.045 in.) 25-30 V 5.8-14.4 m/min (228-567 in./min)
170-300 A 2.4-5.2 kg/h (5-11 lb/h) 1.6 mm (1/16 in.) 25-29 V 3.9-8.2 m/min (154-323 in./min)

Classifications

Weld Metal SFA/AWS A5.22 : E2209T1-4, E2209T1-1
EN ISO 17633-A : T 22 9 3 N L P C1 2
EN ISO 17633-A : T 22 9 3 N L P M21 2

Approvals

Approvals ABS E2209T1-1
ABS E2209T1-4
BV 2205 (C1)
BV SA 2205
CCS 2205-S (C1)
CE EN 13479
CWB E2209T1-1 (C1)
CWB E2209T1-4 (M21)
DNV Duplex (C1)
DNV-GL Duplex (M21)
LR S31803 S (C1, M21)
RINA 2209 S
VdTÜV 09123
Approvals are based on factory location. Please contact ESAB for more information.

Consumable Characteristics

Alloy Type Ni, Cr, Mo, N
Welding Current DC+

Typical Weld Metal Analysis %

Typical Weld Metal Analysis %
C Cr Mn Mo N Ni P S Si Si+Fe
C1
0.03 % 23.2 % 1.40 % 3.21 % 0.14 % 8.7 % 0.025 % 0.012 % 0.60 % 40 %
M21
0.03 % 22.5 % 0.90 % 3.2 % 0.16 % 9.2 % 0.025 % 0.012 % 0.35 % 40 %
