ESAB Shield-Bright 2209 1.2 mm 4x5 kg

See All Reviews

£381.14 inc VAT

£317.62 exc VAT

Availability:

3-5 days

Designed for the welding of 2205 stainless steel.

ESAB Shield-Bright 2209 1.2 mm 4x5 kg

Name: ESAB Shield-Bright 2209 1.2 mm 4x5 kg
Brand: ESAB
SKU: 35HC12560V
Price: 381.14 GBP
Availability: OutOfStock

£381.14

Enquire

Product Code: 35HC12560V

Long Detail

Shield-Bright 2209 was developed for the welding of “2205” duplex stainless steels (UNS S31803, S32205, and J92205).

It can also be used for the welding of leaner grades of duplex stainless steels.

It has been approved with a 25°C critical pitting temperature and impact toughness at -40°C (-40°F).

Technical Spec.

Typical Charpy V-Notch Properties

Impact Value	Testing Temperature
As Welded 80%Ar/20%Co2 Shielding Gas (M21)
52 J (38 ft-lb)	-46 degC (-51 degF)
As Welded Co2 Shielding Gas (C1)
50 J (37 ft-lb)	-46 degC (-51 degF)

Typical Tensile Properties

Condition	As Welded	As Welded
Shielding Gas	80%Ar/20%CO2 Shielding Gas (M21)	CO2 Shielding Gas (C1)
Tensile Strength	810 MPa (117 ksi)	800 MPa (116 ksi)
Yield Strength	670 MPa (97 ksi)	650 MPa (94 ksi)
Elongation	28 %	28 %

Deposition Data

Current	Deposition Rate	Diameter	Voltage	Wire Feed Speed
130-220 A	1.9-4.6 kg/h (4-10 lb/h)	1.2 mm (0.045 in.)	25-30 V	5.8-14.4 m/min (228-567 in./min)
170-300 A	2.4-5.2 kg/h (5-11 lb/h)	1.6 mm (1/16 in.)	25-29 V	3.9-8.2 m/min (154-323 in./min)

Classifications

Weld Metal

SFA/AWS A5.22 : E2209T1-4, E2209T1-1
EN ISO 17633-A : T 22 9 3 N L P C1 2
EN ISO 17633-A : T 22 9 3 N L P M21 2

Approvals

ABS E2209T1-1
ABS E2209T1-4
BV 2205 (C1)
BV SA 2205
CCS 2205-S (C1)
CE EN 13479
CWB E2209T1-1 (C1)
CWB E2209T1-4 (M21)
DNV Duplex (C1)
DNV-GL Duplex (M21)
LR S31803 S (C1, M21)
RINA 2209 S
VdTÜV 09123

Approvals are based on factory location. Please contact ESAB for more information.

Consumable Characteristics

Alloy Type	Ni, Cr, Mo, N
Welding Current	DC+

Typical Weld Metal Analysis %

Typical Weld Metal Analysis %
C	Cr	Mn	Mo	N	Ni	P	S	Si	Si+Fe
C1
0.03 %	23.2 %	1.40 %	3.21 %	0.14 %	8.7 %	0.025 %	0.012 %	0.60 %	40 %
M21
0.03 %	22.5 %	0.90 %	3.2 %	0.16 %	9.2 %	0.025 %	0.012 %	0.35 %	40 %
