With innovative ESAB technology and industry-leading productivity enhancements, Warrior has the features you need and the innovation you expect.
Multiple-Process
| Description or Qualifier | w/Cooling Unit | |
| Height | 470 mm | 700 mm |
| Length | 712 mm | 712 mm |
| Width | 325 mm | 325 mm |
| Description or Qualifier | w/Cooling Unit | |
| Weight | 59 kg | 74 kg |
| Model | 400i CC/CV | 500i CC/CV | |
| Energy Save Mode | 30 W | ||
| Power Factor at Maximum Current | 0.91 | ||
| Efficiency at Maximum Current | 88 % | 89 % | |
| Open Circuit Voltage | 54 (VRD 28) VDC | ||
| Protection Class | IP23 | ||
| Current Range(A) | 16-400 (TIG 5-400) A | 16-500 (TIG 5-500) A | |
| Fuse Slow - Amps | 25 A |
| Fuse Slow - Amps | 32 A |
| Model | 400i CC/CV | 500i CC/CV |
| MIG/MAG | 400 A/34V @ 60% 300 A/29V @ 100%  |
500 A/39V @ 60% 400 A/26V @ 100%  |
| MMA | 400 A/36V @ 60% 300 A/32V @ 100%  |
500 A/40V @ 60% 400 A/36V @ 100%  |
| TIG | 400 A/26V @ 60% 300 A/22V @ 100%  |
500 A/30V @ 60% 400 A/26V @ 100%  |
| Voltage | 380-415 ± 10% V |
| Phase | 3 |
| Frequency | 50/60 Hz |
| MCableX | 4x6 |
For specifications on compatible wire feeders please see separate fact sheet and manual.
