Fronius Vizor Crystal Welding Helmet


£730.80 inc VAT

£609.00 exc VAT

Availability:

3-5 days

Detailed and high-contrast: In addition to its wide field of vision, the Vizor Crystal features unique glare protection technology. In light conditions, you can perceive color almost as clearly as you would through a clear glass window. In darkness, welders have a detailed and high-contrast view of the weld pool, with unprecedented clarity.

Fronius Vizor Crystal Welding Helmet

£730.80

Product Code: 42.0510.0396
Download PDF

Long Detail

Detailed and high-contrast: In addition to its wide field of vision, the Vizor Crystal features unique glare protection technology.

In light conditions, you can perceive color almost as clearly as you would through a clear glass window. In darkness, welders have a detailed and high-contrast view of the weld pool, with unprecedented clarity.

  • Thanks to the latest solar technology, the lithium-polymer battery can either be charged with welding light or ambient light. Alternatively, you can also charge the battery via a Micro-USB interface with any conventional USB battery charger.

  • The display is adapted to the eye and opens smoothly, significantly reducing eye strain in comparison to a normal delay function (twilight function)

  • The nose cut gives the welder up to six times the field of vision of conventional welding helmets.

  • In grinding mode, the auto-darkening filter cartridge remains deactivated. This ensures interference-free grinding.

  • The light transmission level of 31% at shade level 2 when open allows for a virtually perfect view of your working environment.

  • Thanks to the autopilot, you no longer need to set the shade level yourself. The auto-darkening filter cartridge darkens automatically and regulates independently between 4 and 12, according to the arc intensity.

Technical Spec.

Field of Vision Thanks to the nose cut, depending on the headband setting, 2.3 to 6.3 times the field of vision of a 100x50 mm industry-standard auto-darkening filter cartridge.
Levels of Protection

Autopilot: 2.0 (Light Condition)
4 < 12 (Dark Condition)

Autopilot inactive: 2.0 (Light Condition)
7-12 (Dark Condition)

Sensitivity Seamlessly adjustable, with “super high” sensitivity
Eye Protection Ultraviolet/infrared protection: maximum protection across all levels of protection
Switching Time For Light to Dark 0,090 ms at room temperature, 0,070 ms at 55 °C
Switching Time from Dark to Light 0,1–2,0 s (dimming function)
Classification According to EN379 Optical Class: 1, Scattered Light Class: 1, Homogeneity Class: 1, Angle Dependence Class: 2
Power Supply Rechargeable lithium-polymer battery via Micro-USB cable, supported by solar cells
Charging Time Approx 1 Hour
Weight 0.61Kg
